ACT-588
Integrated non-volatile memory secures data even when out of signal or power-off Industrial design: impact-proof and dust-proof Multiple connectivity options for receiver: RS232, PS/2 or Data transmission distance reaches 300m in open area 2000mA Lithium-ion battery ensures long working hours Detachable battery offers easy replacement and charging
Features:
■ Integrated non-volatile memory secures data even when out of signal or power-off
■ Industrial design: impact-proof and dust-proof
■ Multiple connectivity options for receiver: RS232, PS/2 or USB
■ Data transmission distance reaches 300m in open area
■ 2000mA Lithium-ion battery ensures long working hours
■ Detachable battery offers easy replacement and charging
Technical Parameter:
| Performance | ||
| Light Source | 650nm Laser | |
| Frequency | 433MHz | |
| Communication Distance | 300m(max.) | |
| Resolution (pcs0.9) | 0.10-0.825mm | |
| Scan Width | 60mm at 30mm; 100mm at 100mm |
|
| Depth of Field | 10-420mm | |
| Scan Rate | 45 scans/sec. | |
| Electrical | ||
| Receiver voltage | DC 5V | |
| Battery | 2000mA Lithium ion battery | |
| Working Current | 85mA | |
| Environmental | ||
| Operating Temperature | 0℃-45℃ | |
| Storage Temperature | -20℃ - 60℃ | |
| Humidity | 5%-95% (non-condensing) | |
| Lumination | 5000Lux (max.) | |
| Physical | ||
| Dimention | 80x60x160mm | |
| Material | ABS | |
| Weight | 240g | |
