ACT-80W
High speed of printing up to 250mm/s Firmware download available 2D barcode printing support Anti-electromagnetic interference level 3
Feature
Specification
Printing Method
Thermal Line
Resolution
8dots/mm, 576dots/line
Effective Printing Width
72mm
Printing Speed
250mm/s or 220mm/s
Character Set
ASCII, GB18030(Chinese),BIG5
Self-defined Character
YES
Print Font
ANK: 12 x24 Chinese:24x24
Barcode
1D: UPC-A，UPC-C，EAN-13，EAN-8，CODE39，ITF25，CODEBAR，CODE93，CODE128, 2D:PDF417,QR CODE, DATA matrix
Graphic
Support bitmap downloading
Paper End Sensor
YES
Overheating Protection
YES
Interface
RS-232/Parallel/USB/Ethernet
/WIFI (Reserved)
Cash drawer control
DC24V,1A,6PIN RJ-11Socket
Power Supply (Adapter)
AC100 ~240V ± 10%(include) DC 24V, 2A
TPH
100KM
Auto Cutter
5,000,000 cuts
Paper Type
Thermal paper
Paper Width
79.5± 0.5mm
Paper Thickness
0.06 to 0.08mm
Paper Roll Diameter
Max.80mm
Auto Cutter
Partial Cut
Operating Temp/Humidity
5-50°C/10%-80%
Storage Temp/Humidity
-20-60°C / 10%-90%
Dimension (LxWxH)
200x139x150mm
