CPU

Intel® Atom™Processor D2550

Memory

1 x DDR3 2GB

Network

RTL8168DE PCI-E Gigabit Ethernet NIC

Power Supply

100-240V/ 3.5A 47~63Hz

Video Card

Intel Graphics Media

Sound Card

Accelerator3150(256MB/Intel)

RTL ALC662 @INTEL 82801G(ICH7)High Definition Audio

Dimension

290X200X310mm

O.S. Compliant

Windows XP / VISTA/WIN7/WIN8(opitional)

HDD

M-SATA 32 G

I/O PORTS

USB: 4 x USB 2.0 port

Serial Port: 3 x DB-9 RS232

LAN: 1 x 10/100/1000 Mbps

Audio: Interface x 1

VGA: 1 x DB-15 VGA Interface

HDMI: N/A

DISPLAY

Viewing Angle: 85 degree adjustable

LCD: 12" TFT LCD

Max. Resolution: 1024 x 768

Touch Screen: 5-wires resistive 20,000,000 times touch life (P-CAP multi-touch optional)

ENVIRONMENT

Operation Temperature: 0~40℃

Storage Temperature: -40~50℃

Humidity: 38~80%℃
